SOAP ADREESS LOOKUP API

The AddressSearchByIndex function is used to drill down a hierarchy of matched items to locate a specific address and obtain its details. The initial search criteria is an index name and value. The address can be returned in a default format or can be customised into a formatted label. Individual address elements and additional data items may also be returned.

The search function is achieved via three separate requests; AddressSearchByIndex, AddressExpand and AddressDetails.

1. The AddressSearchByIndex request initiates the search for the given search criteria plus request options, and returns a list of matched items. This requires both an Index and Value search parameter. The Index parameter must be the full name of an indexable field. The Value parameter specifies the search criteria within that field. It may contain single character (?) or multi character (*) wildcards, but must not start with a wildcard character. All other parameters are optional and should only be supplied when a non-default configuration is required.
2. The AddressExpand request continues the search, by expanding a specific matched item, and returns a new list of matched items at the next search level. This is repeated until no further expansion is possible.
3. The AddressDetails request obtains the address and associated data for a specific matched item.

NOTE: The AddressSearchByIndex function is only available when the Master Address File contains appropriate data. For further details please refer to the How do I discover the searching capability of a given MAF? below.

Below is an example AddressSearchByIndex Request for “Hopewiser Ltd” against the “ORGANISATION” indexed field.

<soapenv:Body>
  <hpw:AddressSearchByIndexRequest xmlns:hpw="http://hopewiser/soapaddrsvr">
    <hpw:Index>ORGANISATION</hpw:Index>
    <hpw:Value>Hopewiser Ltd</hpw:Value>
  </hpw:AddressSearchByIndexRequest>
</soapenv:Body>

The response will always contain a status code and description (see Status Codes section below). Please note if a search does not fully complete (i.e. find all possible matches), then the entire request will be treated as a failure and an appropriate status code/description will be returned (e.g. “Too many matches”).

Successful responses will also contain one or more matched items. Each matched item will contain a number attribute (a simple count) and the elements listed below.

Below is an example of an AddressSearchByIndex response for “Hopewiser Ltd” against the “ORGANISATION” indexed field…

Address Expand Request

The AddressExpand request continues a search, by expanding a specific matched item, and returns a new list of matched items at the next search level. This should be repeated until no further expansion is possible.

Matched items with either the Expandable flag value yes or the ExpandableToName* flag value yes can be expanded.

It only requires the SID (Search IDentity) of the matched item to be expanded. This will have been obtained from either the initial search request or a preceding AddressExpandRequest.

All other parameters are optional and should only be supplied when a non-default configuration is required.

Below is an example AddressExpand request – continuing the search for “Hopewiser Ltd” against the “ORGANISATION” indexed field.

<soapenv:Body>
  <hpw:AddressExpandRequest xmlns:hpw="http://hopewiser/soapaddrsvr">
    <hpw:SID>
      %+0%@ORGANISATION@HOPEWISER LTD0p%uk-rm-paf%single_step%250
      %EnglishAndWelsh%yes%no%no
    </hpw:SID>
  </hpw:AddressExpandRequest>
</soapenv:Body>

The response will always contain a status code and description (see Status Codes section below). Please note if a search does not fully complete (i.e. find all possible matches), then the entire request will be treated as a failure and an appropriate status code/description will be returned (e.g. “Too many matches”).

Successful responses will also contain one or more matched items. Each matched item will contain a number attribute (a simple count) and the elements listed below.

Below is an example AddressExpand response – continuing the search for “Hopewiser Ltd” against the “ORGANISATION” indexed field.

<soapenv:Body>
<hpw:AddressExpandResponse xmlns:hpw="http://hopewiser/soapaddrsvr">
  <hpw:StatusCode>5</hpw:StatusCode>
  <hpw:StatusDesc>Item cannot be expanded</hpw:StatusDesc>
  </hpw:AddressExpandResponse>
</soapenv:Body>

AddressDetails request

The AddressDetails request obtains the address and associated data for a specific matched item.

Generally, a client would only obtain the details of matched items that contain a full address (i.e. those having the Expandable flag value of no). However, it is possible to obtain the details of any matched item.

It only requires the SID (Search IDentity) of the matched item to be expanded. This will have been obtained from either the initial search request or the expansion that followed this using the AddressExpand request.

All other parameters are optional and should only be supplied when a non-default configuration is required.

An example of an AddressDetails request – continuing the search for “Hopewiser Ltd” against the “ORGANISATION” indexed field.

<soapenv:Body>
  <hpw:AddressDetailsRequest xmlns:hpw="http://hopewiser/soapaddrsvr">
    <hpw:SID>
      %+0%@ORGANISATION@HOPEWISER LTD0p%uk-rm-paf%single_step%250
      %EnglishAndWelsh%yes%no%no
    </hpw:SID>
  </hpw:AddressDetailsRequest>
</soapenv:Body>

The response will always contain a status code and description (see Status Codes section below).

Successful responses will also contain a single matched item. The content of the matched item is dependent on the requested options. It will contain a number attribute (value 1) and any combination of the elements listed below. For a basic request this will only be an address.

Below is an example AddressDetails response – continuing the search for “Hopewiser Ltd” against the “ORGANISATION” indexed field.

<soapenv:Body>
  <hpw:AddressDetailsResponse xmlns:hpw="http://hopewiser/soapaddrsvr">
    <hpw:StatusCode>0</hpw:StatusCode>
    <hpw:StatusDesc>Successful</hpw:StatusDesc>
    <hpw:Match number="1">
      <hpw:Address>
        <hpw:Organisation>Hopewiser Ltd</hpw:Organisation>
        <hpw:Line1>Merlin Court</hpw:Line1>
        <hpw:Line2>Atlantic Street</hpw:Line2>
        <hpw:Town>ALTRINCHAM</hpw:Town>
        <hpw:County>Cheshire</hpw:County>
        <hpw:Postcode>WA14 5NL</hpw:Postcode>
        <hpw:DP>1HQ</hpw:DP>
      </hpw:Address>
    </hpw:Match>
  </hpw:AddressDetailsResponse>
</soapenv:Body>

The AddressSearchByName* function is used to drill down a hierarchy of matched items to locate a specific address and obtain its details. The initial search criteria can be a forename* and/or surname* plus an optional address filter. The address can be returned in a default format or can be customised into a formatted label. Individual address elements and additional data items may also be returned.

The actual search and recovery of matched detail is achieved via three separate requests; AddressSearchByName*, AddressExpand and AddressDetails.

1. The AddressSearchByName request initiates the search, for the given search criteria plus request options, and returns a list of matched items.
2. The AddressExpand request continues the search, by expanding a specific matched item, and returns a new list of matched items at the next search level. This is repeated until no further expansion is possible.
3. The AddressDetails request obtains the address and associated data for a specific matched item.

NOTE: The AddressSearchByName* function is only available when the Master Address File contains appropriate data. For further details please refer to the How do I discover the searching capability of a given MAF? below.

AddressSearchByName request*

The AddressSearchByName request* consists of three core parameters; the Forename*, Surname* and optional AddressFilter (Input1..Input10).

• • If the requested MAF only supports surname* searching, then the Surname*  is mandatory.

• • If the requested MAF supports both Forename* and Surname* searching, then either Forename* and/or Surname* parameter must be specified.

• The AddressFilter is optional, but would generally be provided to narrow the search to a specific area. This could be a postcode, a full or partial address. Splitting address elements (e.g. premise name, street, town, etc.) into separate input lines generally yields better results.

NOTE: The maximum number of supported search criteria inputs is 10. This means that only 10 items from the Forename*, Surname* and AddressFilter (Input1..Input10) should be given a value.

All other parameters are optional and should only be supplied when a non-default configuration is required.

Below is an example AddressSearchByName* request for a fictitious person, “Joe Bloggs” in “Altrincham”.

<soapenv:Body>
  <hpw:AddressSearchByNameRequest xmlns:hpw="http://hopewiser/soapaddrsvr">
    <hpw:Forename>Joe</hpw:Forename>
    <hpw:Surname>Bloggs</hpw:Surname>
    <hpw:Input1>Altrincham</hpw:Input1>
  </hpw:AddressSearchByNameRequest>
</soapenv:Body>

The response will always contain a status code and description (see Status Codes section below). Please note if a search does not fully complete (i.e. find all possible matches), then the entire request will be treated as a failure and an appropriate status code/description will be returned (e.g. “Too many matches”).

Successful responses will also contain one or more matched items. Each matched item will contain a number attribute (a simple count) and the elements listed below.

Below is an example AddressSearchByName* response for “Joe Bloggs” in “Altrincham”.

<soapenv:Body>
  <hpw:AddressSearchByNameResponse xmlns:hpw="http://hopewiser/soapaddrsvr">
    <hpw:StatusCode>0</hpw:StatusCode>
    <hpw:StatusDesc>Successful</hpw:StatusDesc>
    <hpw:Match number="1">
      <hpw:SID>
        %+0%JOE@1||BLOGGS@2||ALTRINCHAMmx%uk-test-nc-extract-current
        %single_step%250%EnglishAndWelsh%yes%no%no
      </hpw:SID>
      <hpw:Text>Hopewiser Ltd,Merlin Court,Atlantic Street,
                Altrincham,Cheshire [Mr Joe Bloggs]</hpw:Text>
      <hpw:Expandable>no</hpw:Expandable>
    </hpw:Match>
  </hpw:AddressSearchByNameResponse>
</soapenv:Body>

AddressExpand request

The AddressExpand request continues a search, by expanding a specific matched item, and returns a new list of matched items at the next search level. This should be repeated until no further expansion is possible.

Matched items with either the Expandable flag value yes or the ExpandableToName* flag value yes can be expanded.

It only requires the SID (Search IDentity) of the matched item to be expanded. This will have been obtained from either the initial search request or a preceding AddressExpand request.

All other parameters are optional and should only be supplied when a non-default configuration is required.

Below is an example AddressExpanded request – continuing the search for “Joe Bloggs” in “Altrincham”.

<soapenv:Body>
  <hpw:AddressExpandRequest xmlns:hpw="http://hopewiser/soapaddrsvr">
    <hpw:SID>
      %+0%JOE@1||BLOGGS@2||ALTRINCHAMmx%uk-test-nc-extract-current
      %EnglishAndWelsh%yes%no%no
    </hpw:SID>
  </hpw:AddressExpandRequest>
</soapenv:Body>

The response will always contain a status code and description (see Status Codes section below). Please note if a search does not fully complete (i.e. find all possible matches), then the entire request will be treated as a failure and an appropriate status code/description will be returned (e.g. “Too many matches”).

Successful responses will also contain one or more matched items. Each matched item will contain a number attribute (a simple count) and the elements listed below.

Below is an example AddressExpand response – continuing the search for “Joe Bloggs” in “Altrincham”.

<soapenv:Body>
  <hpw:AddressExpandResponse xmlns:hpw="http://hopewiser/soapaddrsvr">
    <hpw:SID>
       %+0%JOE@1||BLOGGS@2||ALTRINCHAMmx%uk-test-nc-extract-current %EnglishAndWelsh%yes%no%no
    </hpw:SID>
  </hpw:AddressExpandRequest>
</soapenv:Body>

AddressDetails Request

The AddressDetails request obtains the address and associated data for a specific matched item.

Generally a client would only obtain the details of matched items that contain a full address (i.e. those having the Expandable flag value no). However it is possible to obtain the details of any matched item.

It only requires the SID (Search IDentity) of the matched item to be expanded. This will have been obtained from either the initial search request or any  AddressExpand request that followed.

All other parameters are optional and should only be supplied when a non-default configuration is required.

Below is an example AddressDetails request – continuing the search for “Joe Bloggs” in “Altrincham”.

<soapenv:Body>
  <hpw:AddressDetailsRequest xmlns:hpw="http://hopewiser/soapaddrsvr">
    <hpw:SID>
      %+0%JOE@1||BLOGGS@2||ALTRINCHAMmx%uk-test-nc-extract-current
      %single_step%250%EnglishAndWelsh%yes%no%no
    </hpw:SID>
  </hpw:AddressDetailsRequest>
</soapenv:Body>

The response will always contain a status code and description (see Status Codes section below).

Successful responses will also contain a single matched item. The content of the matched item is dependent on the requested options. It will contain a number attribute (value 1) and any combination of the elements listed below. For a basic request this will only be an address.

Below is an example AddressDetails response – continuing the search for “Joe Bloggs” in “Altrincham”.

<soapenv:Body>
  <hpw:AddressDetailsResponse xmlns:hpw="http://hopewiser/soapaddrsvr">
    <hpw:StatusCode>0</hpw:StatusCode>
    <hpw:StatusDesc>Successful</hpw:StatusDesc>
    <hpw:Match number="1">
      <hpw:Address>
        <hpw:Name>Mr Joe Bloggs</hpw:Name>
        <hpw:Line1>Hopewiser Ltd</hpw:Line1>
        <hpw:Line2>Merlin Court</hpw:Line2>
        <hpw:Line3>Atlantic Street</hpw:Line3>
        <hpw:Town>ALTRINCHAM</hpw:Town>
        <hpw:County>Cheshire</hpw:County>
        <hpw:Postcode>W14 5NL</hpw:Postcode>
        <hpw:DP>1HQ</hpw:DP>
      </hpw:Address>
    </hpw:Match>
  </hpw:AddressDetailsResponse>
</soapenv:Body>

The AddressSearchByRadius function is used to drill down a hierarchy of matched items to locate a specific address and obtain its details. The minimum initial search criteria is a grid reference and a search radius (in metres). The address can be returned in a default format or can be customised into a formatted label. Individual address elements and additional data items may also be returned.

The actual search function is achieved via three separate requests; AddressSearchByRadius, AddressExpand and AddressDetails.

1. The AddressSearchByRadius request initiates the search for the given search criteria plus request options, and returns a list of matched items.
2. The AddressExpand request continues the search by expanding a specific matched item, and returns a new list of matched items at the next search level. This is repeated until no further expansion is possible.
3. The AddressDetails request obtains the address and associated data for a specific matched item.

NOTE: The AddressSearchByRadius function is only available when the Master Address File contains appropriate data. For further details please refer to the How do I discover the searching capability of a given MAF? section below.

Below is an example AddressSearchByRadius request for “an area of 1 metre within (0386044, 0391054)”

<soapenv:Body>
  <hpw:AddressSearchByRadiusRequest xmlns:hpw="http://hopewiser/soapaddrsvr">
    <hpw:GridX>0375403</hpw:GridX>
    <hpw:GridY>0386044</hpw:GridY>
    <hpw:Radius>1</hpw:Radius>
  </hpw:AddressSearchByRadiusRequest>
</soapenv:Body>

The response will always contain a status code and description (see Status Codes section below). Please note if a search does not fully complete (i.e. find all possible matches), then the entire request will be treated as a failure and an appropriate status code/description will be returned (e.g. “Too many matches”).

Successful responses will also contain one or more matched items. Each matched item will contain a number attribute (a simple count) and the elements listed below.

Below is an example AddressSearchByRadius response for “an area of 1 metre within (0386044, 0391054)”

<soapenv:Body>
  <hpw:AddressSearchByRadiusResponse xmlns:hpw="http://hopewiser/soapaddrsvr">
    <hpw:StatusCode>0</hpw:StatusCode>
    <hpw:StatusDesc>Successful</hpw:StatusDesc>
    <hpw:Match number="1">
      <hpw:SID>
        %+0%386044@XM||391054@YM||1@RM_G%uk-rm-paf%single_step%250
        %EnglishAndWelsh%yes%no%no
      </hpw:SID>
      <hpw:Text>1 Berwick Avenue,Stockport,Cheshire</hpw:Text>
      <hpw:Expandable>no</hpw:Expandable>
    </hpw:Match>
    <hpw:Match number="2">
      <hpw:SID>
        %+1%386044@XM||391054@YM||1@RMew%uk-rm-paf%single_step%250
        %EnglishAndWelsh%yes%no%no
      </hpw:SID>
      <hpw:Text>2 Berwick Avenue,Stockport,Cheshire</hpw:Text>
      <hpw:Expandable>no</hpw:Expandable>
    </hpw:Match>
    ... etc ...
    <hpw:Match number="70">
      <hpw:SID>
        %+69%386044@XM||391054@YM||1@RMbk%uk-rm-paf%single_step%250
        %EnglishAndWelsh%yes%no%no
      </hpw:SID>
      <hpw:Text>87 Berwick Avenue,Stockport,Cheshire</hpw:Text>
      <hpw:Expandable>no</hpw:Expandable>
    </hpw:Match>
  </hpw:AddressSearchByRadiusResponse>
</soapenv:Body>

Address Expand Request

The AddressExpandRequest continues a search, by expanding a specific matched item, and returns a new list of matched items at the next search level. This should be repeated until no further expansion is possible.

Matched items with either the Expandable flag value yes or the ExpandableToName* flag value yes can be expanded.

It only requires the SID (Search IDentity) of the matched item to be expanded. This will have been obtained from either the initial search request or a preceding AddressExpandRequest.

All other parameters are optional and should only be supplied when a non-default configuration is required.

Below is an example AddressExpanded request – continuing the search for “an area of 1 metre within (0386044, 0391054)”

<soapenv:Body>
  <hpw:AddressExpandRequest xmlns:hpw="http://hopewiser/soapaddrsvr">
    <hpw:SID>
      %+1%386044@XM||391054@YM||1@RMew%uk-rm-paf%single_step%250
      %EnglishAndWelsh%yes%no%no
    </hpw:SID>
  </hpw:AddressExpandRequest>
</soapenv:Body>

The response will always contain a status code and description (see Status Codes section below). Please note if a search does not fully complete (i.e. find all possible matches), then the entire request will be treated as a failure and an appropriate status code/description will be returned (e.g. “Too many matches”).

Successful responses will also contain one or more matched items. Each matched item will contain a number attribute (a simple count) and the elements listed below.

Below is an example AddressExpand response – continuing the search for “an area of 1 metre within (0386044, 0391054)”

<soapenv:Body>
<hpw:AddressExpandResponse xmlns:hpw="http://hopewiser/soapaddrsvr">
  <hpw:StatusCode>5</hpw:StatusCode>
  <hpw:StatusDesc>Item cannot be expanded</hpw:StatusDesc>
  </hpw:AddressExpandResponse>
</soapenv:Body>

Address Details Request

The AddressDetails request obtains the address and associated data for a specific matched item.

Generally a client would only obtain the details of matched items that contain a full address (i.e. those having the Expandable flag value no). However it is possible to obtain the details of any matched item.

It only requires the SID (Search IDentity) of the matched item to be expanded. This will have been obtained from either the initial search request or the preceding AddressExpand request.

All other parameters are optional and should only be supplied when a non-default configuration is required.

Below is an example AddressDetails request – continuing the search for “an area of 1 metre within (0386044, 0391054)”

<soapenv:Body>
  <hpw:AddressDetailsRequest>
    <hpw:SID>
        %+1%386044@XM||391054@YM||1@RMew%uk-rm-paf%single_step%250
        %EnglishAndWelsh%yes%no%no
    </hpw:SID>
  </hpw:AddressDetailsRequest>
</soapenv:Body>

The response will always contain a status code and description (see Status Codes section below).

Successful responses will also contain a single matched item. The content of the matched item is dependent on the requested options. It will contain a number attribute (value 1) and any combination of the elements listed below. For a basic request this will only be an address.

Below is an example AddressDetails response – continuing the search for “an area of 1 metre within (0386044, 0391054)”

<soapenv:Body>
  <hpw:AddressDetailsResponse xmlns:hpw="http://hopewiser/soapaddrsvr">
    <hpw:StatusCode>0</hpw:StatusCode>
    <hpw:StatusDesc>Successful</hpw:StatusDesc>
    <hpw:Match number="1">
      <hpw:Address>
        <hpw:Line1>2 Berwick Avenue</hpw:Line1>
        <hpw:Town>STOCKPORT</hpw:Town>
        <hpw:County>Cheshire</hpw:County>
        <hpw:Postcode>SK4 3AA</hpw:Postcode>
        <hpw:DP>1QD</hpw:DP>
      </hpw:Address>
    </hpw:Match>
  </hpw:AddressDetailsResponse>
</soapenv:Body>

The Indexes function is used to check the searching capabilities and to discover the list of available indexed fields. The MAF supports “index search” when indexed fields are available. The result will also show the NamesAvailable* and RadiusSearchAllowed integer flags that indicate whether the opened MAF supports “name”* and “radius search” respectively.

All MAFs support address searching from a given postcode, full or partial address. Some MAFs may contain additional data that also allows address searching from either a given index name and value, a personal name* or a grid reference and radius.

These additional searching capabilities allow the retrieval of addresses using the methods listed below:

• Address Search By Index
• Address Search By Name*
• Address Search By Radius

An Indexes Request may take an optional MAF parameter to identify the required MAF. If omitted the user’s default MAF will be applied.

The below details an example IndexesRequest function call against a uk-test-xtra-current MAF dataset.

<soapenv:Body>
  <hpw:IndexesRequest xmlns:hpw="http://hopewiser/soapaddrsvr">
    <hpw:MAF>uk-test-xtra-current</hpw:MAF>
  </hpw:IndexesRequest>
</soapenv:Body>

The response will always contain a status code and description (see Status Codes section below). Please note that status code 8 will be returned if the specified MAF does not contain any indexable fields.

Successful responses will also contain integer tags to indicate if the MAF supports name searching (tag NamesAvailable*) and / or radius searching (tag RadiusSearchAllowed). If the MAF supports index searching, then the response will also include a list of available index field names.

Below is an example of a response from an IndexesResponse function call.

<soapenv:Body>
  <hpw:IndexesResponse xmlns:hpw="http://hopewiser/soapaddrsvr">>
    <hpw:StatusCode>0</hpw:StatusCode>
    <hpw:StatusDesc>Successful</hpw:StatusDesc>

    <hpw:RadiusSearchAllowed>0</hpw:RadiusSearchAllowed>
    <hpw:Indexes>
      <hpw:Index>ORGANISATION</hpw:Index>
      <hpw:Index>UDPRN</hpw:Index>
      ... etc ...
    </hpw:Indexes>
  </hpw:IndexesResponse>
</soapenv:Body>

The status code 8 will be returned if the specified MAF does not contain any indexed fields.
